BRS Thin-Section Tapered Roller Bearing for RV Reducer Crank Shaft

Thin-section tapered roller bearing is specially designed for RV-E/RV-C reduction gear, also called crank bearings or crankshaft bearings, with id 10~25mm.

crankshaft Tapered roller bearingRV reducer bearing application

Crank Shaft Bearing-Tapered Roller Bearing Feature

1. Impact load resistance
2. Long service life
3. High precision
4. Low noise

Applications

Automation drive, Industrial robot, reducer, etc.

RV Reducer Crank Shaft Bearing Models

Part NO. Dimension(mm) Mounting(mm) Base Load Ratings(kN) Gear Teeth Mass (kg)
di Da H Li La Cr Cor m z
33001-9.4 9.4 24 12 1 1 13 11 11.7 10.4 RV-20E,RV-25
33001 10 24 12 1 0.5 13 11 11.7 10.4 RV-20E,RV-25
A2125/10 12 27 12 1.2 0.6 13 11 14.7 14.3 RV-20E,RV-42N
30101 12 27 12 1.2 0.6 13 11 15.7 15.3 RV-20E,RV-42N
30202*2J 15 30 12 0.6 0.6 12.7 11 16.3 17 RV-50C
32102 15 30 12 0.6 0.6 13.1 lower deviation 11 16.3 17 RV-50C
30202 15 35 11 1 1 11.75 10 17.1 16.1 RV-50E
32202 15 35 15 1.5 0.6 15 Lower deviation 11.75 23 23.8 RV-80E,RV-70F,RV-120C
32202X1 15 36 15 1.5 0.6 15 Lower deviation 11.75 23 23.8 RV-80E,RV-70F,RV-120C
32004U 20 42 15 0.6 0.6 15 12 26.2 29.9 RV-110E,RV-127F,RV-200C
30204 20 47 14 1.5 1.5 15.25 12 28.2 30.6 RV-160E, CR-320C
30204U 20 47 15 0.8 1 15 Lower deviation 11.5 29 35.8 RV-160E, CR-320C
32204U 20 47 17.5 0.8 1 17 Lower deviation 13 33.7 38.5 RV-320CA, CR-400C
32006X2 30 58 20 1.5 0.6 20 15.5 42.8 51.6 RV-320E, RV-500C
33006X2 30 58 20 2 1.5 19.7 15.5 42.7 51.5 RV-320E, RV-500C
32206X3 30 65 22 2.2 1.2 22 Lower deviation 17.5 63.2 75 RV-450E
